| Short Term Repeatability - White |
.10 ΔE*ab on white ceramic |
| Measurement Geometry |
d/8° |
| Inter-Instrument Agreement |
0.30 ΔE*ab avg. |
| Illumination Spot Size |
14mm |
| Lamp Life |
Approx. 500,000 measurements |
| Light Source |
Gas-filled tungsten lamp |
| Measurement Cycle Time |
≈ 2 seconds |
| Measurement Spot |
8mm |
| Measurement Time |
≈ 2 seconds |
| Photometric Range |
0 to 200% |
| Photometric Resolution |
0.01% |
| Spectral Analyzer |
Blue-enhanced silicon photodiodes |
| Spectral Interval |
10nm |
| Spectral Range |
400nm-700nm |
| Spectral Reporting |
10nm |
| Reflectance Aperture(s) |
1 |
| Humidity |
5% to 85%, non-condensing |
| Operating Temperature Range |
50° to 104°F (10° to 40°C) |
| Storage Temperature Range |
'-4° to 122°F (-20° to 50°C) |
| Dimensions (length, width, height) |
21.3 cm 9.1 cm 10.9 cm |
| Weight |
1.06 kg |
| Package Dimensions (length, width, height) |
51cm, 20cm, 41cm |
| Shipped Weight |
7kg |
| Communication Interface |
USB 2.0 |
| Instrument Display |
Backlit Color Graphic LCD |
| Languages Supported |
English, German, French, Spanish, Italian, Portuguese, Chinese Simplified, Chinese Traditional, Korean, and Japanese |
| Software Development Kit |
XDS4 |
| Battery |
Li-ion |
| Battery Life |
1000 measurements
@ 10 sec intervals |
| Voltage |
100-240VAC 50/60Hz,
12VDC @ 2.5A |
| Calibration |
White and Zero |
| Pass / Fail |
Yes |
| Sample Preview |
Targeting window |
| Transform Support |
Embedded |
| What's Included? |
Instrument with white calibration standard, black trap, manual(CD), AC adapter, carry case |
