Model #: vs450

VS450

Out of Production

The VS450 is a non-contact spectrophotometer used to measure a variety of wet and dry samples including cosmetics, paints, plastics, powders, and food.

Non-Contact Color Measurement Instrument

The X-Rite VS450 is a benchtop spectrophotometer that operates in a non-contact mode. It can measure a sample from a distance without being affected by ambient light. The VS450 can be used to measure wet samples, large or bulky items, or substances such as food that would require a protective barrier for conventional measurement.

In many laboratory and manufacturing processes, it is beneficial to measure wet samples to make a wet-to-wet comparison as a proxy for a final dry-to-dry comparison. This can save as much as 24 hours of wait time while samples dry, enabling operators to make changes in production quickly, reducing scrap and making production more efficient while delivering better color measurements.

Benefits:

  • Control day-to-day color production with a defined, standard procedure that saves time, cost, and effort.
  • Establish a “wet tolerance” in order to produce a good result in a final dry-to-dry comparison.
  • Compensate for the difference in appearance between wet and dry standards, when combined with Color iMatch software.
  • Use this non-contact instrument to measure large or bulky items or materials such as food that may require a protective barrier when using a contact instrument that can affect measurement accuracy.
  • Benefit from minimal maintenance requirements since the optical system never comes in contact with samples and thus remains uncontaminated.

The X-Rite VS450, combined with Color iMatch and/or Color iQC software, enables measurement of wet or dry samples and samples that should not touch the device. It is also capable of measuring samples that change appearance when pressed behind glass or other presentation devices, allowing these samples to be measured in their natural, unaltered state, just as the human eye would see them.

Need More Information?
Meet MetaVue™: A Breakthrough Imaging Spectrophotometer

During this free webinar, you’ll learn how the new MetaVue VS3200 delivers unmatched versatility and color measurement accuracy on difficult-to-measure samples, such as small and non-planar items as well as liquids, pastes, and powders.

Specifications

Short Term Repeatability - White 0.025 max DEab at 12 mm
0.035 max DEab at 6 mm
Short Term Repeatability - Blue Not published
Measurement Geometry 45/0
Inter-Instrument Agreement 0.15 DEab avg on BCRA tiles
Illumination Spot Size Not published
Image Contact During Measurements Non-Contact
Lamp Life 20 million flashes
Light Source Full spectrum LED
Measurement Cycle Time 1 second
Measurement Spot 12 mm and 6 mm
Measurement Time 750 ms
Measurement Working Distance 1.5 inches
Patch Size 6 mm or 12 mm
Photometric Range 0 to 150% reflectance
Photometric Resolution 10 nm intervals
Spectral Analyzer 10 nm intervals
Spectral Range 400-700 nm @ 10 nm
Spectral Reporting 400-700 nm @ 10 nm
Aperture 12 mm and 6 mm
Reflectance Aperture(s) 12 mm and 6 mm
Humidity 0 to 85% RH, non-condensing
Operating Temperature Range 10° to 40° C
Storage Temperature Range -20° to 70° C
Minimum Order Quantity 1
Unit Color Gray
Dimensions (length, width, height) 9.75" L x 6.0" W x 5.57" H
Weight 4.93 pounds
Package Dimensions (length, width, height) 10" L x 17" W x 11" H
Shipped Weight 12 pounds
Communication Interface USB
Software Development Kit Yes
Status Panel No status panel
Voltage Universal power supply, 100-240 VAC
Warm Up Time 3 minutes
Wattage Not published
Industry Standards None published
Calibration White calibration
Embedded NetProfiler Support No
Internal Temperature & Humidity Sensor No
Sample Preview No
Warranty 12 months
