모델 번호
MA-T6 Multi-Angle Spectrophotometer
For 6 Angle Spectral & Texture Measurement
- Measures effect materials with 6 angles of measurement
- Verifies color, sparkle, and coarseness with on-board digital camera
- Minimizes risk of measuring sample defects with live preview
Overview
xxxx Metric
xxx Time
xxxx Geometry
![FPO]()
![FPO]()
![FPO]()
Specifications
x.x
xx
![FPO Image]()
x.x
xx
x.x
xx
x.x
xx
Support
Resources
Video
x.xx
ΔEab
<X
sec
X°/Y°
Product Overview Image Flex 1
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Product Overview Image Flex 2
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Vidyard Video needed
Product Overview Video Flex 1
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Product Overview Image Flex 3
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Vidyard Video needed
Product Overview Video Flex 2
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Vidyard Video needed
Product Overview Video Flex 3
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Product Overview Icon Callout 1
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua
Product Overview Icon Callout 2
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua
Product Overview Icon Callout 3
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua
Product Overview Testimonial 1
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua
Product Overview Workflow Faceting 1
Specification
Design/Premedia
Formulation
Production
Quality Control
Specifications
| Battery | Lithium ion |
| Battery Life | Avg. 800 measurements |
| 교정 | internal white/black calibration; external white |
| Calibration Interval | 30 days |
| Coarseness Repeatability | 0.09% (mean error on median) |
| Coarseness Reproducibility | 1.4% (mean error on median) |
| Color Differences | L*a*b*, L*C*h°, ΔE*; ΔECMC; ΔE DIN6175, ΔE2000 |
| 통신 인터페이스 | USB 2.0 |
| 크기(길이, 너비, 높이) | 266mm x 95mm x 128mm (26.6 cm x 9.5 cm x 12.8 cm) (10.4 in x 3.7 in x 5.0 in) |
| 습도 | 85% relative humidity max (non-condensing) |
| Illuminants | A, C, D50, D65, F2, F7, F11 & F1 |
| Illumination Colors | Polychromatic white LED with blue enhancement |
| Illumination Spot Size | 9x12mm (rectangular) |
| 산업 표준 | ASTM D 2244, E 308, E 1164, E 2194; DIN 6175-1, 6175-2; SAE J1545.ISO 11664-4 |
| 기기 표시 | 3.5 inch (8.9cm) color touch screen display |
| Inter-Instrument Agreement | 0.18 ∆E2000 avg. on BCRA |
| 램프 수명 | 10 years lamp life |
| 지원 언어 | DE, FR, EN, PT, ES, KOR, JA, Chinese, IT |
| Measurement Cycle Time | 5.5 seconds |
| Measurement Geometry | 6 measurement angles (6 illumination sources, 1 pick-up) |
| Measurement Spot | 9x12mm |
| Observers | Colorimetric Standard Observers 2° & 10° |
| 작동 온도 범위 | 50F to 104F (10C to 40C) |
| Positioning | Three positioning pins |
| Short Term Repeatability - White | 0.02 ΔE* |
| Sparkle Measurement | Sparkle Grade, Color Sparkle Parameter, Illumination 15as-15, 15as15, 15as-30, 15as-45, 15as45, 15as80, 15d Diffuse Coarseness |
| Sparkle Repeatability | 0.12% (mean error on median) |
| Sparkle Reproducibility | 1.9 % (mean error on median) |
| Spectral Interval | 10 nm |
| Spectral Range | 400-700 nm |
| 보관 온도 범위 | -4F to 122F (-20C to 50C) |
| 전압 | 7.4vDC @ 2400mAh |
| 품질보증 | 1 year |
| 무게 | 2.64 lbs, 1.2 kgs |
